CTDCG-3-4WD 4WD Car Vehicle Test Lane Vehicle Chassis Dynamometer horse power machine one eddy current 1000hp one free roller

Cartesy Diagnosis Technology CO.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

CTDCG-3-4WD 4WD Car Vehicle Test Lane Vehicle Chassis Dynamometer horse power machine one eddy current 1000hp one free roller

Place of Origin : China

Packaging Details : Wooden packing

Supply Ability : 1 Set/Sets per Month

Price : $8,998.00 - $169,497.00/sets

Brand Name : Cartesysj

Model Number : CTDCG-3-4WD

Certification : CE

MOQ : 1 unit

Payment Terms : L/C,T/T

Delivery Time : 20-25 working days

Name : Automobile Chassis Dynamometer

Car Fitment : BMW - Europe

Warranty : 12 Months

LOAD : 4t

Model Name : CTDCG-3-4WD

Port : Guangzhou

Working voltage (current) : 96V ×35A

The power supply : 220V ±10% 50HZ

Contact Now

CTDCG-3-4WD 4WD Car Vehicle Test Lane Vehicle Chassis Dynamometer horse power machine one eddy current 1000hp one free roller

Product description:

The 4WD horsepower dynamometer is specially used to measure the chassis dynamic performance of the2WD and 4WD vehicles. It can not only accurately measure the dynamic performance at each speed, but also simulate the road to carry out the road test of routine and multi-road of the vehicles, and can also be used for vehicle refitting and ECU debugging and calibration , etc.

Technical parameters:

project

Item

CTDCG-3E

Rated bearing mass of kg

Rated Axle Load

10000kg

Maximum test total mass

3500Kg;

testable horsepower hp

Test house power

1000ph

maximum drawbar pull KN

Max. traction

≥25

Drum diameter and length of mm

Roller diameter × length

Φ373×700mm

Drum inner distance and outer distance are mm

Inner distance of roller × outer distance

700×2100mm

The center of the drum is mm

Distance between roller centers

437mm

Maximum test speed of km m / h

Max.test speed

≥260km/h

Detect wheelbase range

The Test range of wheelbase


Speed indication error

≤±1%

Error in torque representation

≤±2%

Power indication error

≤±2%

weight of equipment

1800Kg;

air supply

Gas source

≥0.8Mpa

supply voltage

AC220V,50Hz

Fan voltage

AC380V,50Hz

Working environment temperature: (℃)

0-40

Benchmark inertia amount of kg

Reference inertia

908kg ±18kg

device for power absorption

Power absorption device

Air-cooled eddy current machine

Air cooled eddy current machine

Rated absorption torsion

Rated Absorbed Torque

1600N.m



CTDCG-3-4WD 4WD Car Vehicle Test Lane Vehicle Chassis Dynamometer horse power machine one eddy current 1000hp one free roller

CTDCG-3-4WD 4WD Car Vehicle Test Lane Vehicle Chassis Dynamometer horse power machine one eddy current 1000hp one free roller

CTDCG-3-4WD 4WD Car Vehicle Test Lane Vehicle Chassis Dynamometer horse power machine one eddy current 1000hp one free roller

CTDCG-3-4WD 4WD Car Vehicle Test Lane Vehicle Chassis Dynamometer horse power machine one eddy current 1000hp one free roller
CTDCG-3-4WD 4WD Car Vehicle Test Lane Vehicle Chassis Dynamometer horse power machine one eddy current 1000hp one free roller
Packing & Delivery
CTDCG-3-4WD 4WD Car Vehicle Test Lane Vehicle Chassis Dynamometer horse power machine one eddy current 1000hp one free roller
CTDCG-3-4WD 4WD Car Vehicle Test Lane Vehicle Chassis Dynamometer horse power machine one eddy current 1000hp one free roller
CTDCG-3-4WD 4WD Car Vehicle Test Lane Vehicle Chassis Dynamometer horse power machine one eddy current 1000hp one free roller

Wooden packing

FAQ
  1. who are we?
    We are based in Guangdong, China, start from 2011,sell to Domestic Market(50.00%),South Asia(10.00%),Africa(10.00%),Eastern Europe(10.00%),Oceania(5.00%),Western Europe(5.00%),Eastern Asia(5.00%),Northern Europe(3.00%),North America(2.00%). There are total about 51-100 people in our office.
  2. how can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;
  3. what can you buy from us?
    Vehicle Sideslip Tester,Roller brake tester with axle load,flat plate test line,Automobile power performance and Chassis dynamometer,Vehicle suspension performance Tester
  4. why should you buy from us not from other suppliers?
    Multi design of overall system scheme Site layout planning and Technological Consulting Systematic site installation and training Online daily maintenance and technical support
  5. what services can we provide?
    Accepted Delivery Terms: FOB,CFR,EXW;
    Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
    Accepted Payment Type: T/T,PayPal,Cash;
    Language Spoken:English,Chinese
